Specifications

Supported Sample Rate

Optical/Coaxial/AES



PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

DSD64 (DoP)







IIS-LVDS

PCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz,



352.8kHz, 384kHz, 705.6kHz, 768kHz



DSD 64/128/256/ (DoP), DSD 64/128/256/512 (Native)



NOTE: Please see the X-SPDIF3 user manual for the IIS-LVDS definition.





System Support

Windows7/8/8.1/10/11 system needs to install the supplied driver.



Mac OS X10.6.4 or above without installing the driver.



Most Android devices can be used via OTG cable.



The iOS devices can be used via Lightning to USB Camera Kit.







Weight and size

Weight 1 kg (2.2 pounds)

Size

Width: 142 mm (5.59 inches)



Depth: 124 mm (4.88 inches)



Height: 38 mm (1.53 inches)







Power Specs

Power Supply Specs



USB bus power supply: 5V/500mA

External power supply: DC 12V, ≥400mA



Power supply plug: Outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)







NOTE

The input power supply should not be higher than 12V, otherwise the product could be damaged.







The USB bus power supply will be disconnected when the external power supply is connected.







An external power supply is required when using the product with low USB output current devices such as mobile phones or tablets.







Accessory

USB cable



x1

Quick start guide



x1

Warranty card



x1
