Specifications：
Hardware Platform:
CPU    NXP i.MX 6Quad Cortex-A9
D/A Chip  ES9038Q2M
Clock Source  Crystek CCHD-950

Digital Input:
Coaxial & Optical
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
DSD 2.8MHz (DoP)

IIS LVDS
PCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz,
352.8kHz, 384kHz, 705.6kHz, 768kHz
DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
DSD 2.8MHz, 5.6 MHz, 11.2 MHz, 22.4MHz (Native)

USB Audio
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz,
352.8kHz, 384kHz, 705.6kHz, 768kHz

MQA
16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz,
352.8kHz, 384kHz MQA or MQA Studio stream
DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (Native)

HDMI ARC
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Line Output:
XLR
SNR: >-120dB A-weighting
THD+N:<0.00025%@1k, <0.00035%@20Hz-20kHz
Frequency Response: 20Hz-20kHz ±0.1 -3dB@80kHz
Crosstalk: >-138dB
Output Level: 4VRMS@0dB

RCA
SNR: >-118dB A-weighting
THD+N:<0.00035%@1k, <0.00050%@20Hz-20kHz
Frequency Response: 20Hz-20kHz ±0.1 -3dB@80kHz
Channel Crosstalk: >-130db
Output Level: 2VRMS@0dB

Headphone Output:
4.4 mm balanced
SNR: >-116dB A-weighting
THD+N:<0.0006%@20Hz-20kHz 4VRMS
Frequency Response: 20Hz-20kHz ±0.1 -3dB@65kHz
Output Impedance:<22Ω
Output Power: 1500mw@33Ω, 950mw@300Ω, 500mw@600Ω, 1%THD
Gain: +16.5dB

6.35mm unbalanced
SNR: >-114dB A-weighting
THD+N:<0.0008%@20Hz-20kHz 2VRMS
Frequency Response: 20Hz-20kHz ±0.1 -3dB@65kHz
Output Impedance:<11Ω
Output Power: 1200mW@33Ω, 260mW@300Ω, 130mW@600Ω, 1%THD
Gain: +16.5dB

Power Specs:
Power Voltage
AC 100-240V 50/60Hz
Standby Power Consumption< 5W
Maximum Power Consumption< 30W

Weight: 2.6 kg (5.73 pounds)
