Specifications
Product type Preamplifier
Inputs 3x XLR combo (balanced) / 6.35mm TRS jack (single-ended)
Output 1x Balanced XLR pre-out
Other connectors 12V trigger input (3.5mm jack)
Trigger Output 12V (3.5mm jack)
Total harmonic distortion more noise (THD+N) 0.00005% @ 1kHz, A-wt
0.00003% @ 20-20kHz, 90kBW
Signal-to-noise ratio (SNR) 151dB @ Max out, 1kHz, A-wt
Dynamic range 151dB @ 1kHz, A-wt
Frequency response 20Hz-40kHz (±0.05dB)
20Hz-100kHz (±0.1dB)
Output level 69Vpp @ G=L
65Vpp @ G=M
65Vpp @ G=H
Audio Precision Noise Level Measurement < 0.7µVrms @ G=L
< 1.2µVrms @ G=M
< 2.5µVrms @ G=H
Effective noise level < 0.3µVrms @ G=L
< 0.9µVrms @ G=M
< 2.3µVrms @ G=H
Crosstalk -150dB @ A-wt
Input sensitivity 25.3Vrms @ G=L
7.1Vrms @ G=M
2.3Vrms @ G=H
Gain 0dB @ G=L
+10.4dB @ G=M
+19.9dB @ G=H
Input impedance 20kΩ
Output impedance 100Ω
General
AC power supply 100-240VAC 50Hz/60Hz
Dimensions 330x57x20mm
Weight 2.55Kg
Package 1x Topping Pre900
1x Remote control
1x Power cable
