Technical Details

Dimensions
115 × 70 × 18 mm
Weight
205 g
DAC
Four CS43198
AMP
Two SGM8262
CPU
Snapdragon 665
Memory
4 GB RAM + 64 GB ROM + MicroSD card slot
System
Open Android 13
Display
4.7-inch Sharp 1280 × 720
Bluetooth Transmitter
v5.0 LDAC / aptX HD / aptX / SBC
Bluetooth Receiver
v5.0 LDAC / SBC
Hi-Res Support
PCM up to 32-bit / 768 kHz & DSD512
Battery
3500 mAh; up to 14 h single-ended / 11 h balanced
3.5 mm Output Power

Low gain
12.5 mW @ 32 Ω
Medium gain
50 mW @ 32 Ω
High gain
200 mW @ 32 Ω
THD+N
0.000007
Separation
75 dB @ 32 Ω
Dynamic Range
127 dB
Signal-to-noise ratio
127 dB
Noise
< 1.1 µV
Output impedance
< 1 Ω
4.4 mm Output Power

Low gain
50 mW @ 32 Ω
Medium gain
200 mW @ 32 Ω
High gain
800 mW @ 32 Ω
Frequency Response
20 Hz–40 kHz (- 0.2 dB)
THD+N
0.000007
Separation
110 dB @ 32 Ω
Dynamic Range
130 dB
Signal-to-noise ratio
130 dB
Bottom noise
< 1.6 µV
Output impedance
1.5 Ω
Inside the Box
  • 1 x Shanling M3 Plus
  • User Manual
