Penon TAIL

Specification
Model: TAIL
Chip: dual CS43131
DAC: DSD64, DSD128, DSD256
Decoding rate: PCM 384KHZ/32bit and below
USB port: TYPE-C
USB protocol: UAC2.0 protocol, UAC1.0 protocol
Support Impedance: 16-600Ω
Output: 3.5mm audio + 4.4mm balanced
Frequency response: 20Hz-20kHz
SNR: 130dB@4.4mm/ 4Vrms,125B@3.5mm/ 2Vrms
THD+N: -103dB@4.4mm /4Vrms,100B@3.5mm/ 2Vrms
Crosstalk suppression: -135dB@4. 4mm/ 4Vrms, -85B@3.5mm/ 2Vrms
High precision femtosecond crystal oscillator: 100fs
Output performance
3.5mm output(low gain) 32Ω @1kHz, connect with PC
Impedance: 32Ω @1kHz
Output level: minimum: 900mV, 25.3mW; typical: 1000mV, 31.25mW; maximum: 1200mV, 45mW
Frequency response: 20-20kHz
THD+N: minimum -105dB, typical -100dB, maximum -95dB
SNR: minimum 110dB, typical 120dB, maximum 130dB
DNR: minimum 110dB, typical 120dB, maximum 130dB
Crosstalk: minimum -65dB, typical -60dB, maximum -55dB
3.5mm output(high gain) 600Ω @1kHz, connect with PC
Impedance: 600Ω @1kHz
Output level: minimum: 1800mV, 5.4mW; typical: 2000mV, 6.67mW; maximum: 2200mV, 8.07mW
Frequency response: 20-20kHz
THD+N: minimum -105dB, typical -100dB, maximum -95dB
SNR: minimum 115dB, typical 125dB, maximum 135dB
DNR: minimum 115dB, typical 125dB, maximum 135dB
Crosstalk: minimum -95dB, typical -85dB, maximum -75dB
4.4mm balanced output(low gain) 32Ω @1kHz, connect with PC
Impedance: 32Ω @1kHz
Output level: minimum: 1800mV, 101.25mW; typical: 2000mV, 125mW; maximum: 2200mV, 151.25mW
Frequency response: 20-20kHz
THD+N: minimum -105dB, typical -103dB, maximum -100dB
SNR: minimum 120dB, typical 125dB, maximum 130dB
DNR: minimum 120dB, typical 125dB, maximum 130dB
Crosstalk: minimum -110dB, typical -105dB, maximum -100dB
4.4mm balanced output(high gain) 600Ω @1kHz, connect with PC
Impedance: 600Ω @1kHz
Output level: minimum: 3800mV, 24.07mW; typical: 4000mV, 26.67mW; maximum: 4200mV, 29.4mW
Frequency response: 20-20kHz
THD+N: minimum -105dB, typical -103dB, maximum -100dB
SNR: minimum 125dB, typical 130dB, maximum 135dB
DNR: minimum 125dB, typical 130dB, maximum 135dB
Crosstalk: minimum -140dB, typical -135dB, maximum -130dB
Package
Penon TAIL
