| Drive Units | |
|---|---|
| Uni-Q Driver Array | HF: 25 mm (1 in.) aluminium dome LF/MF: 130 mm (5.25 in.) magnesium/aluminium alloy cone |
| Frequency | |
| Frequency range (-6dB) measured at 85dB/1m | 38Hz – 20kHz *Depends on EQ Settings |
| Frequency response (±3dB) measured at 85dB/1m | 41Hz – 20kHz *Depends on EQ Settings |
| Amplification | |
| Amplifier output power (per speaker) | LF: 70W HF: 30W |
| Amplifier class (per speaker) | LF: Class D HF: Class D |
| Max SPL measured at 1m | 102 dB |
| Wireless & Streaming | |
| Wireless streaming features | Bluetooth 5.4 aptX Adaptive™, aptX Lossless™ |
| Source resolution | Optical up to 96kHz/24bit USB Type C up to 192kHz/24bit HDMI up to 1.411 Mbps PCM *Depends on source resolution |
| Interspeaker connection | Wired: all sources resampled to 96kHz/24bit PCM |
| Dimensions & Weight | |
| Dimensions (H × W × D per speaker) | 285 x 168 x 268 mm (11.2 x 6.6 x 10.55 in.) |
| Weight (per set) | 11.3 kg |
| Power | |
| Power input | 100 – 240VAC 50/60Hz |
| Power consumption | 200W (operating) / <0.5W (standby) |
| Primary Speaker | |
| Inputs | HDMI Optical USB Type C RCA (Without Phono stage) RCA (With Phono stage) USB Type C (interspeaker) Bluetooth |
| Output | RCA Subwoofer output USB Type C (interspeaker) USB Type C (5V DC) |
| Secondary Speaker | |
| Inputs | USB Type C (interspeaker) |
