iBasso Jr. Macaron HiFi DAC

Portable HiFi DAC for Music Lovers

The iBasso Jr. Macaron is a compact, high-performance DAC designed to deliver high-quality audio across various platforms, including Win, Mac, Android, and iOS devices. It offers professional-grade sound with its flagship dual Cirrus Logic CS43131 DAC chips, advanced circuitry, and a sleek design. This is the perfect solution for anyone looking for better sound quality than traditional TWS earphones can provide.

Key Features

Dual CS43131 DAC Chips

iBasso Jr. Macaron is equipped with two flagship CS43131 DAC chips from Cirrus Logic, which are typically found in high-end audio players. With an ultra-low noise floor, dynamic range of 132dBA, and signal-to-noise ratio (SNR) of 132dBA, this DAC provides outstanding sound quality without distortion.

Low Power Consumption

The Macaron operates at only 80mA, ensuring that your phone's battery remains unaffected, even when connected to an iPhone, which has power supply limitations.

Advanced Jitter Reduction with KDS Femto Oscillator

The Macaron features a KDS femto clock oscillator, which significantly reduces jitter and distortion in audio signals. This ensures highly accurate sound reproduction, with every nuance of your music preserved in the highest quality.

Aluminum Alloy Body with Tempered Glass

The Macaron features an elegant aluminum alloy CNC body, complemented by double-sided tempered glass. Available in four stylish colors—Black, Silver, Pink, and Blue—it is designed to be both lightweight and durable, fitting comfortably in any pocket.

Interchangeable Cable Design

Included with the Macaron is a high-quality single-crystal copper silver-plated Type-C to Type-C cable. The interchangeable cable design allows you to easily switch between 3.5mm single-ended and 4.4mm balanced plugs to match your headphones.

Wide Codec Support

The iBasso Jr. Macaron supports up to PCM 32bit/384kHz and native DSD256, ensuring compatibility with a wide range of high-resolution audio formats. It also includes five digital filters, two output modes, and hardware volume control with 100 levels of adjustment for precise tuning.

Specifications

  • DAC Chip: Dual CS43131
  • PCM Support: Up to 32bit/384kHz
  • DSD Support: Native DSD256
  • Weight: 16g
  • Dimensions: 41.7mm x 24mm x 12.3mm
  • THD+N (4.4mm Balanced): 0.00013% (300Ω load)
  • THD+N (3.5mm Single-ended): 0.00016% (300Ω load), 0.00045% (32Ω load)
  • Output Power (4.4mm Balanced): 4.0Vrms
  • Output Power (3.5mm Single-ended): 1.65Vrms (32Ω load), 2.0Vrms (300Ω load)
  • SNR (Balanced): 132dBA
  • SNR (Single-ended): 128dBA
  • Frequency Response: 20Hz - 40kHz (-0.5dB)
  • Output Impedance: <0.2Ω (Balanced), <0.1Ω (Single-ended)

Package Contents

  • iBasso Jr. Macaron DAC
  • Type-C to Type-C Cable (Single-crystal copper, silver-plated)
  • Quick Start Guide
  • Warranty Card
