iBasso DX320

Features:
>Flagship Dual DAC chipset with 2xBD32301EKV DAC chips from ROHM.
>In-house developed FPGA master controller.
>Excellent Performance With Industry-leading SNR and THD+N ratings.
>Patented Dual Battery Power Supply structure.
>Ultra-fast lag-free performance with Snapdragon 660 SoC.
>Replaceable AMP card.
>Stock AMP11 MK2s chipset.
>Stunning 6.5” display(2340x1080P resolution).
>Dual operating systems(Android 11 & Mango OS).
>Professional-grade Parametric Equaliser.
>True MQA 16X support.
>Bluetooth V5.0 connectivity.
>High-speed Wifi connectivity.
>Up to 10 hours of continuous music playback.
>Supports QC3.0, PD3.0 quick charging.

Technical Specs:
>Model: DX320.
>Screen: 6.5” IPS display.
>USB Type: Type-C 3.1.
>RAM+ROM: 6GB+128GB.
>Battery Capacity: 4000mAh for digital section, 2000mAh for AMP card section.
>Charging Time: 2.5H.
>Dimensions: 162x77x17mm.
>Weight: 205grams.

AMP11 MK2s Specifications:
>Output Ports: 4.4mm/2.5mm balanced/3.5mm single-ended headphone outputs, 3.5mm coaxial output, USB OTG output.

4.4mm/2.5mm balanced output specs:
>Maximum output level: 7.1Vrms.
>Output power: 1200mW@32Ω, 168mW@300Ω.
>Frequency Response: 10Hz-40kHz.
>SNR: 125dB.
>Dynamic Range: 125dB.
>THD+N: Up to -112dB.
>Crosstalk: -120dB.
>Output impedance: 0.38Ω.

3.5mm SE output specs:
>Max output level: 3.5Vrms.
>Output power: 380mW@32Ω, 40mW@300Ω.
>Frequency Response: 10Hz-40kHz.
>SNR: 122dB.
>Dynamic Range: 122dB.
>THD+N: Up to -110dB.
>Crosstalk: -114dB.
>Output impedance: 0.34Ω.

iBasso DX320 is the latest flagship Android Digital Audio Player designed with top-quality audio components. It's a no compromise digital audio player equipped with TOTL level components such as flagship Dual DACs from ROHM, a Patented Dual Battery System, an 8-core SoC from Qualcomm, Swappable amplification modules, and many more features. iBasso has featured their in-house developed FPGA-Master architecture that makes sure audio is given full priority task on the DX320. Upgrade your portable setup with the brand-new DX320!!

True Hi-Res Experience:
iBasso DX320 is a flagship-grade digital audio player. It is equipped with a dual DAC chipse featuring two of the latest launched BD34301EKV DAC chips designed by ROHM Technologies. The chips are from the latest MUS-IC™ series of premium decoding chips by ROHM. The BD34301EKV DAC chips offer excellent performance with class-leading ultra-low Distortion and clean SNR ratings.

In-House Developed FPGA Master Audio Technology:
With the help of two high-performance Accusilicone femtosecond crystal oscillators, iBasso has designed a custom FPGA Master Technology. It requests the audio signal directly from the SoC and provides it directly to the DAC chips and the audio circuitry. This not only reduces the lag in the transmission but also provides an uninterrupted sound experience with the DX320!!

Patented Dual-Battery Architecture:
Battery and power supply play an important role in any given audio chain. They might make or break the sound output quality. iBasso with years of expertise has equipped the flagship DX320 with their patented Dual-Battery design. In this design, the DAC, SoC, and other components are powered by a 4000mAh battery pack. There's a second 2000mAh battery pack specifically for the amp section. In this manner, the AMP section gets its own power and provides clean amplification.

Swappable AMP Modules:
Similar to other flagships from iBasso, the latest DX320 also supports swappable amplification modules. It means that you can easily switch the AMP module on the DX320 to your liking. iBasso has included AM11 MK2s as the stock with the DX320.

AMP11 MK2s Amplification Module:
The stock module of the DX320(AMP11 MK2s) houses three headphone output ports, 3.5mm single-ended, 4.4mm balanced, and 2.5mm balanced ports. All three of these ports also support line-out to connect further amplifiers in the chain. The 3.5mm headphone output also has Coaxial output support.

Dual Operating Systems:
iBasso DX320 is loaded with two different operating systems, Open Android 11 OS and Linux-Based Mango OS. Android variant will obviously have a wide catalog of media application support while the Mango OS will be a pure music player experience. With the latest Snapdragon 660 SoC, 6GB RAM, the DX320 works flawlessly without any lag or stutters.

Stunning 6.5” Display:
iBasso DX320 houses a large 6.5” full-screen display with super-thin bezels. It produces crisp images with stunning clarity. The screen has a resolution of 2340x1080 pixels.
