Amplifier
Input Connector: XLR x2, RCA x2
Vac:
Output: Amperex 17BF11 x2
Driver:  Amperex ECF82/6U8 Rectifier
Rectifier: RCA 17AX4GT
Dimension: 270mm x 215mm x 143mm
Weight: 10kg
N220v-240V
Fuse:
~220v-120v: T500mAL250v
~100v-120v: T1AL250v
Output Tube Fuse: Tl 25mAE250V
Power Consumption: 60w
Working Condition: Temp:-20C-70C; Humidity: 20%-80%
Storage Condition: Temp:-20C-70C; Humidity: 20%-90%

Headphone output
Rated Output*
4pin XLR (BAL): 800mW (L); 900mW (M); 1000mW (H)
4.4mm (BAL): 200mW (L); 300mW (M); 270mW (H)
6.35mm (SE): 330mW (L); 550mW (M); 750mW (H)
Frequency Range: 20Hz~50kHz ±3dB
TH+D: 0.2% (1 kHz, 100mW)
Sensitivity: 450mV~600mV
S/N Ratio: 100dB (A-Weighted)
Headphone Impedance: L: 8-64Ω; M: 65-250Ω; H: 251-600Ω
Headphone Connectors: 4pin XLR x 1, 4.4mm x 1, 6.35mm xl
* Output per channel

Vacuum Tube Substitution
Vacuum Tube: Substitution
Amperex 17BF11: 17BF11A
Amperex ECF82/6U8: ECF82, 61-JG
RCA 17AX4GT: 17AX4GTA
